Graphite PTFE Filament Packing

Discover Kaxite Sealing's Graphite PTFE Filament Packing, the ultimate sealing solution for demanding industrial applications. Engineered with premium graphite and PTFE filament, it ensures superior durability, chemical resistance, and leak prevention, ideal for pumps, valves, and compressors. Experience unmatched reliability and reduced downtime—upgrade your systems with our advanced packing today and achieve seamless, efficient performance. Trust in quality that safeguards your operations.

Send Inquiry

Product Description

Description:
Cross-plaited packing of high strength graphite yarn, impregnated with PTFE dispersion and graphite powder to increase density and sealing efficiency. Braided by high strength PTFE filament LENMENS yarn with graphite impregnation. The characteristics are similar to "CGFO".

Typical Application
> Wide range of media across many industrial sectors.
> Its versatility with valves, rotary equipment and reciprocating pumps allows users to standardise on one range of packing for the majority of their general plant.

Prime Features
> Universal application across an industrial site
> Excellent chemical and thermal resistance
> Good thermal conductivity
> Excellent lubricity

Technical Data

Material		100% Filament Graphite PTFE yarn impregnated with PTFE
Temperature Range		-150 up to +280 ^oC
Process	Rotating	30 bar
	Reciprocating	100 bar
	Static	200 bar
Shaft Speed		25m/s
PH		0~14
Density		1.65g/cm³
